Laboratories: Mechanical Engineering

Sr. No.	Name of Laboratory	Room No.
01	CAD/CAM Lab	GF15
02	Dynamics of Machinery Lab	GF16
03	Heat Transfer Lab	GF17
04	Theory of Machines Lab	GF20
05	PG Research Lab	GF22
06	Metallurgy Lab	GF21
07	Ph.D. Research Lab	GF23
08	Refrigeration Lab	GF24
09	IC Engine Lab	GF25
10	Ph.D. Research Lab 2	GF26
11	Metrology Lab	GF27
12	Fluid Machinery Lab	GF28
13	Steam Lab	GF28
14	Fluid Mechanics Lab	GF28
15	Automation Lab	GF19A
16	Central Computer Centre	CCF1
17	Tutorial Room I Cum Departmental Library	GF18
18	Seminar Hall	FF27
19	Drawing Hall	FF28

Sr. No.	Name of Major Equipment	Amount (Rs.)
1	FFT Analyzer	12,07,500/-
2	Computerized Multi-Fuel Research Engine Set-up	9,73,125/-
3	Jash Accord Series Bridge Type 3D Coordinate Measuring Machine	8,13,780/-
4	Journal Bearing Test Rig	6,09,140/-
5	Wear and Friction Monitor	6,02,270/-
6	CNC Lathe Trainer H–E-125 CNC-PC	5,28,430/-
7	Vacuum Stir Casting Furnace	5,00,000/-
8	Planetary Ball Mill	4,00,000/-
9	Steam Turbine Test Rig	3,93,750/-
10	Water Softener (Model: AQUASOFT-005)	3,81,360/-
11	Non-IBR Steam Boiler (400 kg/hr, 15 kg/cm², Model: Steampack-400)	2,04,750/-
12	Auto Collimator (Model ACT-01S, Single Axis with Standard Mirror ACC-3 SPC)	1,65,064/-
13	HP DesignJet 500 Plus A0 Colour Printer	1,39,000/-
14	Ductility Testing Machine	1,02,150/-
15	Tubular Sintering Furnace	1,00,000/-
16	INDUS Smoke Meter Complete with Sampling System	91,530/-
17	Portable Ultrasonic Flaw Detector (Model 4400)	89,804/-
18	Triple Vertical Shaft Kaplan Turbine Test Rig (Complete Set)	89,240/-
19	Vapour Absorption Cycle Test Rig	85,000/-
