| Sr. No. | Name of the Lab | Major Equipments | Area of Laboratory (Sq.m) | Cost of Laboratory (Rs.) |
|---|---|---|---|---|
| 1 | Machine Lab I & Machine Lab II |
1. AE make rectifier unit 3ph 360–440V, 50Hz AC input, Output 230–250V DC 0–100A. 2. Variable Frequency Drive with Motor 0.5HP, 3ph, 415V, 4 Pole & 2 Pole. |
145 | 1327565.00 |
| 2 | Basic Electrical Lab | — | 73 | 147152.00 |
| 3 | Measurement Lab | Phase Shift Transformer, 3 Phase, 1000VA, 415V. | 73 | 112264.00 |
| 4 | Power Electronics & IDC Lab |
1. 1-Phase Dual Converter Fed Separately Excited DC Motor. 2. Thyristor Controlled Trainer with 0.5HP 3-Phase Induction Motor (TCT-3 Motor). 3. 3HP Induction Motor PWM Control using IGBTs. |
73 | 496479.00 |
| 5 | Power System Lab |
1. MATLAB & Simulink Software Suite with Control System, Fuzzy Logic, Neural Network, Signal Processing & SimPower Toolboxes. 2. ETAP Power Station Software (Educational Version). 3. DC Network Analyzer. |
73 | 1420329.00 |
| 6 | Analog & Digital Lab | Analog Lab Trainer T2612 (Ready-to-use Circuit Board). | 73 | 488833.00 |
| 7 | Microprocessor & Microcontroller Lab | Logic Analyzer Model LA2142, 100 MHz Sampling, 128K Channels. | 73 | 654482.00 |
| 8 | Control System Lab + NA + PLC | Study of PID Control System. | 73 | 760258.00 |
| 9 | Switchgear & Protection Lab |
1. Transformer Protection Simulation (Merz-Price Scheme). 2. Distance Protection Simulation Model. 3. Universal Solid State Relay Kit. |
73 | 427832.00 |
| 10 | High Voltage Lab |
1. AC High Voltage Transformer (60 kVA). 2. 0–100 kV Oil Testing Kit. 3. HCL Pentium-4 Computer System. 4. Intel Pentium-III Computer. |
73 | 550218.00 |
| 11 | Computer Lab I |
1. Intel Pentium-III Computer Set (Configuration 1). 2. Intel Pentium-III Computer Set (Configuration 2). |
83 | 2728025.00 |
| 12 | Testing Lab |
1. Digital Earth Resistance Tester. 2. Microprocessor-Based Cable Fault Localizer. |
— | 458861.00 |
| Total | 9572309.00 | |||
